CJ-T2-AC 275V 20-40ka 1-4p Ngwa nchekwa ọkụ ọkụ ọkụ SPD egosipụtara

CJ-T2-AC 275V 20-40ka 1-4p Ngwaọrụ nchekwa ọkụ ọkụ ọkụ SPD

Nkọwa dị mkpirikpi:

Maka nrụnye na LPZ0A -1 ma ọ bụ karịa, na-echebe akụrụngwa voltaji dị ala megide ọkụ na-emebi emebi.
Tinyere na PSD Class I + II (Klas B + C) maka usoro inye ọkụ dị iche iche. Ekepụtara dị ka IEC 61643-1 / GB 18802.1.

Zitere anyị email

Nkọwa ngwaahịa

Mkpado ngwaahịa

Njirimara nhazi

10/350μs, 8/20μs sparkgap.
Otu ogwe ọkụ ọkụ ugbu a njide, pluggable.
Nabata hermetical GDT trchnology, ike na-ekpochapụ ugbu a dị elu.
Ọkwa nchebe voltaji dị oke ala.
Ọnụ ụzọ abụọ maka njikọ myirịta ma ọ bụ usoro(ụdị V).
Njikọ ọtụtụ ọrụ maka ndị nduzi na bọsbars.
Window akwụkwọ ndụ akwụkwọ ndụ ga-agbanwe na-acha ọbara ọbara mgbe mmejọ dakwasịrị, na-enyekwa ihe mkpuchi anya n'otu oge.
N'ihi na iji elu-arụmọrụ MOV na kacha ga-10/350 7kA.

Data teknụzụ

Ụdị	CJ-T2-AC
Egosiri voltaji (max.continuous avoltage) [UC]	275V ma ọ bụ 385V
Ọkụ ọkụ dị ugbu a (10/350) [limp]	7kA
Mwepu aha ugbu a (8/20) [ln]	20kA
Mwepu kacha ugbu a [Imax]	50kA
Ọkwa nchekwa voltaji [Elu]	≤1.5kV
Soro ike mkpochapụ ugbu a na Uc [Ọ bụrụ]	32A fuse agaghị akpalite na 2kAms 255V
Oge nzaghachi [tA]	≤100ns
Max.ndabere fuse(L)	200AgL/gG
Max.ndabere fuse (L-L')	125AgL/gG
Ọnụ ego TOV	355V/5 nkeji
Oke okpomọkụ na-arụ ọrụ (wiring yiri ya) [Tup]	-40ºC…+80ºC
Oke okpomọkụ na-arụ ọrụ (site na wiring) [Tus]	-40ºC…+60ºC
Mpaghara gafere	35mm² siri ike / 50mm² mgbanwe
Na-agbanye	35mm DIN okporo ígwè
Ihe mkpuchi	Purple (modul) / isi awọ (isi) thermoplastic, UL94-V0
Akụkụ	2 mods
Ụkpụrụ ule	IEC 61643-1;GB 18802.1 ;YD/T 1235.1
Ụdị kọntaktị nrịbama dịpụrụ adịpụ	Ịgbanwe kọntaktị
Ịgbanwe ikike ac	250V/0.5A
Ike ịgbanwee dc	250V/0.1A;125V/0.2A;75V/0.5A
Mpaghara gafere maka kọntaktị nrịbama dịpụrụ adịpụ	Oke.1.5mm2 siri ike / mgbanwe
Ngalaba nkwakọ ngwaahịa	1pc(s)
Ibu	385g
